Schneider Electric EcoStruxure Panel Server

When it comes to electrical safety, power availability, and energy sustainability, it is important to have the right information in the right place, at the right time.

EcoStruxure Panel Server is the next generation of gateway, making power monitoring simple and cyber-secure. It provides a seamless connection of wired or unwired smart IoT devices to your edge control software or cloud-based applications and analytics. The EcoStruxure Panel Server is a foundational enabler for Schneider Electric EcoStruxure solutions.

Analyse power usage, monitor power distribution, detect equipment problems, and send alarm notifications - the EcoStruxure Panel Server makes the most of your data.

Power availability

Avoid unplanned downtime caused by an electrical failure with electrical distribution monitoring and power event analysis.

Energy efficiency

Reduce your facility’s energy consumption with energy usage analysis and performance tracking.

Cybersecurity

This IEC 62443-compliant device helps with the vital task of guarding your electrical assets and systems against cyberattacks.

Electrical safety

Reduce the risk of electrical fires and increase the protection of people and assets with continuous thermal monitoring applications.

All-in-one gateway

• Separates your OT network from your IT network
• Wireless data concentrator
• Modbus RS485 to Modbus TCP
• Supports multiple Ethernet connections for serving information to edge control software and cloud applications

Simple commissioning

• EcoStruxure Power Commission software for device setup
• Device auto-discovery
• Generation of acceptance reports validating gateway configuration
• Commission via WiFi

Intuitive operation

• User-friendly webpages offer first-level monitoring
• Contextualized data and operational insights
• Simple alarm set up for email notification

Integration with EcoStruxure Cybersecurity Admin Expert

• Central to the IEC 62443-3-3 SL1 certified EcoStruxure Power system
• Manage user accounts, define cybersecurity policy and retrieve security logs

Standards and certifications

• Standardized IEC 62974-1 compliant datalogger and energy server
• ISO 50001, 50002, 50006 (energy data management system)
• IEC 61010-1 Ed.2010, UL 61010-1 Ed.2012, IEC 61974 (electrical safety)

Real-time monitoring

• Real-time data collection and alarms
• Information presented through embedded webpages
• Data available easily to edge control software or digital services for electrical diagnostics
